Traffic Rated Septic Tank - 1500 gal - Baffle Access - Bioconcrete

SKU:
200050544

Septic tanks are buried, watertight container that collects wastewater and separates solids from liquids. Jensen offers concrete and fiberglass tanks.

  • Capacity: 1,500 gallons
  • Access Position: Baffle
  • Load Class: Traffic
  • Material: Bioconcrete

IAPMO Research and Testing Product Listing

Delivery available to:
  • Arizona
  • Northern California
  • Southern California

Product availability varies by location. If you need a product immediately, contact us to ensure availability.

If you need modifications to a standard product or a complete custom solution, we will work to accommodate your request in a timely manner. Please provide us with a few details about your project. Contact us now.

Features & Benefits

The JP 1500 septic tank, the perfect solution for your residential and commercial wastewater management needs. This septic tank is designed to meet the highest standards, adhering to ACI 318 and ASTM C890 design specifications, with a load rating of A-16 (AASHTO HS20-44).

Crafted from precast concrete, the JP 1500 is built to last. It has a rectangular shape, and its outside dimensions are 75 inches in height, 128 inches in length, and 70 inches in width. With a maximum gallon capacity of 1,500 gallons, this septic tank is ideal for homes and businesses of all sizes.

The JP 1500 septic tank is compliant with the International Plumbing Code (IPC) and Uniform Plumbing Code (UPC), and is IAPMO certified according to IAPMO/ANSI Z1000-2019.

The septic tank’s access configuration features 24″E, 24″B, and 24″E, while the bury depth ranges from 1.1 to 6.0 feet. It also features a 4-inch pipe size (ID – Nominal) for easy installation and maintenance.

The JP 1500 septic tank is reinforced with BioConcrete admixture, making it a more sustainable and eco-friendly choice. This septic tank weighs 19,122.86 pounds, providing excellent durability and stability.

In conclusion, the JP 1500 septic tank is a reliable and efficient septic tank that meets the highest standards in the industry. With its outstanding features and quality materials, you can trust this septic tank to provide excellent wastewater management for your property.

Product Resources

Technical Specifications

Weight: 19122.86 lb
Product Type: Septic Tank
Series: 1500
Application: Septic Systems
Model: JP
Gallon Capacity (Max): 1,500 gallons
Pipe Size (ID - Nominal): 4 in.
Access Configuration: Baffle
Load Class: Traffic Rated
Material: Bioconcrete
Design Specification: ASTM C890, ACI 318
Load Rating: A-16 (AASHTO HS20-44)
Height (Outside): 100 in.
Bury Depth: 1.1' - 6.0'
Bury Depth Reference: Top
Length (Outside): 128.25 in.
Width (Outside): 67.25 in.
Water Table Elevation: Below Structure
Invert Height: 59 in.
Delivery to: Arizona, Northern California, Southern California
Compliance: International Plumbing Code (IPC), Uniform Plumbing Code (UPC)
IAPMO Certification: IAPMO/ANSI Z1000-2019
Tank Shape: Rectangular
